"G.S. Wire for ACSR Conductors"

AARTI STEEL INTERNATIONAL LIMITED manufacture ACSR wires in the dia range 1.57 mm to 4.09 mm. The manufacturing capacity of the wire is 6000 METRIC TONNES PER YEAR. This wire is processed on the most modern high speed drawing machines and is galvanized in an ultra-modern Galvanizing Furnace with Nitrogen Wiping which has been introduced in Nov 2022. The general properties of these wires are given here under

Chemical Composition :

Carbon Silicon Manganese Sulphur Phosphorus
0.50 to 0.85% 0.10 to 0.35% 0.50 to 1.10% 0.045% Max 0.03% max.


Physical/Mechanical Property:

  • Diameter & Tolerances: The wire dia and wire tolerances of ACSR wires are maintained as per IS-398 Pt 2-1996 & IS-398 Pt 5-1992 or as specified by customer.
  • Breaking Load : Breaking Load ACSR wires is maintained as per IS-398 Pt 2-1996 & IS-398 Pt 5-1992 or as specified by customer.
  • Ductility Test : The ductility test of ACSR wires is carried out as per IS-398 Pt 2-1996 & IS-398 Pt 5-1992 or as specified by customer.
  • Wrap Test : The wrap test of these wire is done as per IS-398 Pt 2-1996 & IS-398 Pt 5-1992 or as specified by customer.
  • Galvanizing Test : The Galvanizing test of ACSR core wires are done as per IS-398 Pt 2-1996 & IS-398 Pt 5-1992 or as specified by customer.

Packing : Coil weight of ACSR Core wire and packing is done as per customer requirement.
