Steel Wire for Ropes

"Steel Wires, Uncoated and Galvanized, For Ropes"

AARTI STEEL INTERNATIONAL LIMITED have manufacturing capacity to produce uncoated & galvanized Rope Wire from 0.25 mm to 5.00 mm diameter. The manufacturing capacity of these wire is 3600 METRIC TONNES PER YEAR. The general properties of these wires are given hereunder:

CHEMICAL COMPOSITION OF STEEL WIRE FOR ROPES :

Carbon % Manganese % Silicon % Phosphorous % Sulphur % Copper % Nickel % Chromium %
0.35 – 1.00 0.30 – 0.90 0.10 – 0.35 0.25 Max 0.02 Max 0.06 max 0.05 max 0.05 max

Physical/Mechanical Properties:

  • Tolerance on Diameter : Wire dia and wire tolerances are maintained as per IS-1835-1976 or as per customer’s requirements.
  • Tensile Strength : The tensile strength of the wire is maintained as per IS-1835-1976 or as per customer’s requirements.
  • Torsion Numbers : The torsion nos. of the wires are controlled as per customer's specifications/IS-1835:1976.
  • Reverse Bend Test : This test is carried out as per IS-1716/1835 & number of reverse bends are maintained as per IS-1835:1976.
  • Wrap Test : Wrap test of wire is conducted as per IS-1835:1976 or as specified by customers.
  • Mass of Zinc Coating : The zinc coating weight on wire surface is maintained as per IS-1835:1976 or as specified by customer.
  • Uniformity of Zinc Coating : The uniformity of zinc coating is checked as per IS-1835:1976/IS-2633 or as specified by customer.
  • Adhesion Test for Galvanized : The adhesion of zinc coating with steel wire is checked as per IS-1835:1976 or as specified by customer.

Coil Dimensions & Coil Weight:

Size (mm) Coil ID (mm) Coil OD (mm) Coil Weight(Kgs.)
0.25-0.40 130 260 10-15
0.41-0.78 160 360 15-28
0.79-1.33 290 400 40-80
1.34-1.45 480 600 80-150
1.46-2.80 480 600 100-200
2.81-3.10 480 600 100-200
3.11-4.00 630 900 150-300
4.01-5.00 730 950 200-500

Packing : Packing of the wires is done as per customer requirements.
